Encouraging Accessibility Best Practices with Cypress.io

January 24, 2021

When building a web site or application with accessibility in mind, laundry lists of rules and requirements come to mind. This often leads organizations to adopt accessibility checklists that hopefully provide designers and engineers with a concrete series of requirements that all products must meet.

Despite their complexity, nearly all of these requirements start with a foundation in semantically valid HTML. Though this may sound like a low bar to meet, many engineers struggle to write semantically valid markup, particluarly when those engineers may have more expertise in pure programming rather than the ins-and-outs of HTML.

Abstractions Upon Abstractions

When building for the web using modern JavaScript frameworks, oftentimes the actual DOM that is being rendered to the page is abstracted away via several layers of custom components. These abstractions are great on the surface - they allow for code re-use, visual consistency, and UX consistency. Unfortunately, custom components can also cause engineers to lose the forest for the trees, and ignore the final, rendered markup with which end users interact.

Take this JSX that renders a page with a data table of recipes:

export function MyRecipesPage() {
  <Page title="My Recipes">
    <SortableTable data={recipes}>
    <Button to="/">Go Back</Button>
  </Page>
}

Looks great! The page works as expected and the code is easy to read thanks to component abstractions. But how can an engineer have confidence that these components are rendering valid markup? What if that <Button> component is incorrectly rendering an HTML button instead of an anchor tag? What if <SortableTable /> is just a series of div and span tags rather than a semantically meaningful data table?

Automated Testing

Ideally, a layer of automated testing at the component level would catch these problems, while also encouraging engineers to choose components available to them that render semantically valid markup.

Enzyme Shallow Mounting

For years in the React community, testing a page component like this would probably start with using Enzyme, a library with utilities for testing React components in a Node-based virtual DOM environment like jsdom. One would probably start with something like this using Enzyme's shallow method:

describe('MyRecipesPage', () => {
  it('renders a Page with a title', () => {
    const wrapper = shallow(<MyRecipesPage />)
    const page = wrapper.find('Page')

    expect(page).toExist()
    expect(page).toHaveProp('title', 'My Recipes')
  })

  it('renders a SortableTable with recipes data', () => {
    const mockRecipes = []
    const wrapper = shallow(<MyRecipesPage recipes={mockRecipes} />)
    const table = wrapper.find('SortableTable')

    expect(table).toExist()
    expect(table).toHaveProp('data', mockRecipes)
  })

  it('renders a Button that returns the user to the landing page', () => {
    const wrapper = shallow(<MyRecipesPage recipes={mockRecipes} />)
    const button = wrapper.find('Button')

    expect(button).toExist()
    expect(button).toHaveProp('to', '/')
  })
})

These tests look like they are verifying the rendered output - but all they are doing is verifying that the components used in the page component were actually returned. Do these tests provide future engineers with confidence in the final rendered DOM? Assuming future engineers were interested in testing the HTML semantics of the page, they might be concerned with answering the following questions:

  • Does <MyRecipesPage /> have a valid heading?
  • Is the data rendered in a valid HTML table?
  • Does the button actually render as a link or does it (incorrectly) render as an HTML button?

Cypress to the Rescue

Refactoring these tests with Cypress can help address some of these concerns:

describe('"My Recipes" page', () => {
  beforeEach(() => cy.visit('/recipes'))

  it('renders with a relevant page title', () => {
    cy.title().should('include', 'My Recipes Page') // Checking for a unique <title />
    cy.get('h1').should('be.visible').should('contain', 'My Recipes Page')
  })

  it('renders with a table that contains recipe data', () => {
    cy.get('table').should('be.visible')
    // Verify data renders as expected
    cy.get('tbody tr').eq(0).should('contain', 'Chicken Pot Pie')
    cy.get('tbody tr').eq(1).should('contain', 'Green Curry')
  })

  it('renders with a link to go back to the home page', () => {
    cy.get('a')
      .should('be.visible')
      .should('contain', 'Go Back')
      .should('have.attr', 'href', '/')
  })
})

Great! Now these tests run in the browser and are grabbing elements from the DOM instead of React component abstractions that may or may not be producing the markup we are expecting.

These tests can be taken a step further using Cypress Testing Library.

Cypress Testing Library

Cypress Testing Library offers a series of methods to help query elements more granularly, allowing room for code refactors as well as the addition of new features to the page. If the page were to introduce an additional link, for example, the prior test checking for the home page anchor tag would fail:

export function MyRecipesPage() {
  <Page title="My Recipes">
    <SortableTable data={recipes}>
    <Button to="/">Go Back</Button>
    <Button to="https://google.com">Find More Recipes</Button>
  </Page>
}

And now this test would need to changed:

it('renders with a link to go back to the home page', () => {
  // This test was broken by the introduction of another anchor tag!
  // Not ideal since the original "Go Back" link continued to work as expected.
  cy.get('a')
    .eq(0)
    .should('be.visible')
    .should('contain', 'Go Back')
    .should('have.attr', 'href', '/')

  cy.get('a')
    .eq(1)
    .should('be.visible')
    .should('contain', 'Find More Recipes')
    .should('have.attr', 'href', 'https://google.com')
})

Instead of grabbing raw HTML elements, the cy.findByRole method (made available via Cypress Testing Library) can be used to check for valid, accessible DOM output all while reducing the risk of test brittleness:

describe('"My Recipes" page', () => {
  beforeEach(() => cy.visit('/recipes'))

  it('renders with a relevant page title', () => {
    cy.title().should('include', 'My Recipes Page')
    // Using the `name` option helps grab the relevant heading that contains the content we are looking for
    cy.findByRole('heading', { name: 'My Recipes Page' }).should('be.visible')
  })

  it('renders with a table that contains recipe data', () => {
    cy.findByRole('table').within(() => {
      cy.get('tbody').within(() => {
        cy.findAllByRole('row').eq(0).should('contain', 'Chicken Pot Pie')
        cy.findAllByRole('row').eq(1).should('contain', 'Green Curry')
      })
    })
  })

  it('renders with a link to go back to the home page', () => {
    // This test will not be as brittle - it will find a link that has this content
    // no matter how many links are added to the page.
    cy.findByRole('link', { name: 'Go Back' }).should('have.attr', 'href', '/')
    cy.findByRole('link', { name: 'Find More Recipes' }).should(
      'have.attr',
      'href',
      'https://google.com'
    )
  })
})

So Cypress Testing Library helped solve three key problems with testing the recipes page UI:

  1. The tests are much less brittle now that they no longer rely on the order of DOM elements (nor will they break when new elements are introduced to the page)
  2. The tests are able to handle valid HTML semantics whether they are derived from native HTML tags or valid ARIA roles
  3. When future engineers work on this page, it will be more difficult to introduce invalid HTML even if such a bug were introduced via a higher level abstraction

An engineering team that leans heavily on cy.findByRole as their primary means of querying elements in their tests will also catch accessibility problems earlier. If an element is tough to query via cy.findByRole, that probably means that a screen reader user (or even search engine crawler) would have trouble interpreting the page as well and is an early indication that an accessibility bug is present.

Wrapping Up

Moving away from testing higher level abstractions with tools like Enzyme helps protect against the introduction of invalid markup. By leveraging Cypress and Cypress Testing Library (particluarly the cy.findByRole method) engineers can make automated testing less brittle and ensure their markup is meeting accessibility requirements all within a real browser environment.
